Full material kit — every unit
Reference specification. Final spec confirmed at order stage.
Our standard home designs use the baseline specifications below. Final specifications are adapted to your local building codes, site conditions and project requirements.
| Item | Base Specification / Design Target |
|---|---|
| Structural System | Engineered light-gauge steel framing |
| Steel Grade & Coating | G550 steel with AZ150 coating |
| External Wall Frame | 89 mm depth; steel thickness and spacing determined by engineering |
| Wind Resistance Target | N3 — ultimate design gust speed 50 m/s (180 km/h) |
| Roof Snow Load Allowance | 0.25 kPa, subject to local snow and drift assessment |
| Seismic Design | Site-specific seismic engineering; Importance Level 2 for the Australian residential design basis |
| Residential Floor Live Load | 1.5 kPa |
| Balcony Live Load Allowance | 2.0 kPa, subject to size and use |
| Roof Maintenance Live Load Allowance | 0.25 kPa for non-trafficable roofs; concentrated loads checked separately |
| Dead Loads | Calculated from the actual materials, finishes and fixed equipment |
| Solar Equipment Load Allowance | Additional 0.15 kPa; equipment supply excluded unless quoted |
| Wall Insulation | R2.5 |
| Ceiling Insulation | R3.5 |
| Suspended-Floor Insulation | R2.5, where applicable |
| Windows | Double-glazed aluminium windows |
| Window Thermal Target | Whole-window Uw ≤2.5 W/(m²·K) |
| Wall Acoustic Targets | External opaque walls: Rw ≥45 dB; selected insulated internal partitions: Rw ≥35 dB |
Pay securely with PayPal
Two fixed steps: a $2000 design fee to start, then a $5000 deposit to confirm production. No shipping cost — these confirm your build.
Starts the custom design for Lucas House.
Confirms production after design is approved.
What to know before ordering
Everything that is not included in the FOB price is listed here.
Other foldable models
All FOB Ningbo · material kit only.
